Staircase Calculator
A professional tool for Indian architects and interior designers. NBC 2016 compliance, Blondel's formula, pitch verification, stringer length and one-click BOQ export — all in one screen.
Inputs
Slab-to-slab distance (typical 2700–3200 mm)
NBC max 190 mm · comfortable 160–180 mm
NBC min 250 mm · comfortable 275–300 mm
Residential min 900 mm (NBC)
Results
Risers
17
Treads
16
Riser
176
mm
Tread
275
mm
4.40 m
5.33 m
42.6 sqft
Compliance Checks
NBC Riser Height
NBC max 190 mm · your actual 176 mm
176 mm
NBC Tread Depth
NBC min 250 mm · your value 275 mm
275 mm
Blondel's Formula (2R + G)
Comfort band 600–640 mm
628 mm
Pitch Angle
Ideal 30°–38°
34.3°
Headroom: NBC requires minimum 2100 mm vertical clearance above any tread nosing.
Vastu note: This design has 17 risers (odd — traditionally preferred).
Method
How it works
The calculator takes your floor-to-floor height and divides it by your target riser height, rounded to the nearest whole number. This gives the number of risers. The actual riser height is then the total height divided by that count — ensuring every step is identical, which is critical for safety and comfort.
The number of treads is always one less than the number of risers, because the top riser lands directly on the upper floor slab. Horizontal run is treads × tread depth, and the stringer length (sloping support) comes from the Pythagorean theorem.
Four compliance checks run on every result:
- NBC Riser (≤190 mm) — National Building Code 2016, residential.
- NBC Tread (≥250 mm) — National Building Code 2016, residential.
- Blondel's Formula (2R + G = 600–640 mm) — the classic comfort rule used in French and British code for over 300 years.
- Pitch Angle (30°–38° ideal) — below 27° is a ramp, above 42° is a ladder.
FAQ
Common questions about staircase design
What is the NBC 2016 limit for staircase risers and treads in India?
NBC 2016 specifies a maximum riser height of 190 mm and a minimum tread depth of 250 mm for residential staircases. Commercial and public buildings have stricter limits (riser ≤ 150 mm, tread ≥ 300 mm). This calculator enforces the residential values.
How does Blondel's formula work?
Blondel's formula states that 2 × Riser + 1 × Tread (Going) should fall between 600 mm and 640 mm for a comfortable staircase. Architects have used this rule since 1675. The calculator flags any design outside this range so you can adjust before going to site.
What is the ideal pitch angle for residential stairs?
A comfortable domestic staircase has a pitch angle between 30° and 38°. The calculator marks 30°–38° as ideal (green), 27°–42° as acceptable (amber), and anything outside as uncomfortable (red). Commercial stairs are typically steeper; fire escape stairs follow separate rules.
Why does the calculator use actual riser height for Blondel, not target?
Blondel checks the real walkable dimensions. Target riser is what you want; actual riser is what the user will step on (total height ÷ number of risers). The calculator uses actual riser to give you a true comfort reading — critical when the target does not divide cleanly into the floor height.
Can I export the result as a BOQ?
Yes. Click Copy BOQ to get a plain-text block with all dimensions — risers, treads, riser height, tread depth, stair width, total run, stringer length, pitch angle, Blondel value, and stair footprint. Paste directly into quotations, BOQ sheets, or contractor briefs.
Does the calculator account for landings or U-shaped stairs?
Version 1 handles straight-flight staircases. For L-shaped or U-shaped stairs with intermediate landings, divide the flight at the landing and run the calculator for each segment — the landing itself is treated as an enlarged tread (minimum size = stair width).
Why does my 16-riser stair show 'even — consider odd' in the Vastu note?
Traditional Vastu Shastra recommends an odd total riser count (3, 5, 7, 9, 11, 13, 15, 17). This is a cultural preference, not a structural requirement. If your client requests Vastu compliance, adjust your target riser slightly to land on an odd number — the calculator will help you iterate.
